SAM Series Semi-Automatic Horizontal Mixing Filling Machine

1. Product Overview

The SAM Series Semi-Automatic Horizontal Mixing Filling Machine is designed for filling sauces containing solid particles and other viscous materials. Equipped with an integrated mixing system, it ensures uniform material consistency, smooth discharge, and high filling accuracy. The hopper is available with optional heating and temperature-preservation functions, making it suitable for viscous sauces containing solid particles.

2. Main Technical Parameters

Item	Specification
Power Supply	220V / 50Hz
Filling Valve	Piston-type anti-drip filling valve
External Start Options	Foot pedal, proximity switch, photoelectric sensor
Drive and Control System	Servo motor + PLC pulse control
Mixing Hopper Drive	Worm gear speed-control motor, 750W
Air Consumption	≤ 0.1 m³/min (compressed air used only for the anti-drip valve)
Applicable Materials	Chili sauce, hot pot base, chili oil sauce, and various particle-containing sauces

Model Specifications

Model	Filling Volume (mL/cycle)	Motor Power (kW)	Filling Accuracy	Mixing Hopper Capacity	Hopper Dimensions (mm)	Mixing Motor Power (kW)	Outlet Diameter (mm)	Machine Dimensions (L × W × H, cm)	Weight (kg)
SAM-5	5–1,000	0.75	≤ 1 g	80 L	600 × 380 × 450	0.75	25	65 × 32 × 82	68
SAM-10	5–1,000	0.75	≤ 1 g	80 L	600 × 380 × 450	0.75	32	80 × 35 × 82	90
SAM-20	5–10,000	2.0	≤ 5 g	100 L	600 × 380 × 500	0.75	38	90 × 38 × 90	120
SAM-35	5–100,000	2.6	≤ 10 g	100 L	600 × 380 × 500	0.75	51	110 × 48 × 95	190
SAM-60	10–100,000	3.8	≤ 20 g	100 L	600 × 380 × 500	0.75	63	110 × 48 × 100	225
SAM-120	20–100,000	5.5	≤ 50 g	200 L	750 × 500 × 600	1.5	89	120 × 55 × 130	306

Note: Please confirm the filling volume ranges and filling accuracy specifications with the manufacturer before publication or ordering.

3. Key Features

1. Integrated Mixing Hopper: The built-in mixing system helps prevent solid particles from settling, maintains uniform material consistency, and supports stable filling performance.

2. Servo Motor and PLC Control: The servo-driven PLC pulse control system enables precise filling quantity adjustment. The piston-type anti-drip valve helps prevent dripping after filling.

3. Multiple Triggering Options: Supports foot pedal operation and photoelectric sensing, making it suitable for semi-automatic production lines with manual bottle placement.

4. Food-Grade Stainless Steel Construction: The machine features a stainless steel structure. An optional heated and temperature-controlled hopper is available for materials that solidify at low temperatures, such as beef tallow hot pot base.

5. Low Air Consumption: Compressed air is required only for operating the anti-drip valve, helping reduce air consumption during operation.

4. Suitable Materials

The SAM Series is suitable for filling viscous sauces containing solid particles, including:

• Chili sauce
• Hot pot base
• Chili oil sauce
• Beef sauce
• Shiitake mushroom sauce

It is particularly suitable for applications requiring uniform mixing, accurate quantitative filling, and reliable handling of particle-containing viscous sauces.
